| Delivery time | Shipped in 2 - 3 - Day(s) |
| Article number | 46432 |
| EAN | 6096003053086 |
| Dimensions | Inch |
| Size | 3" |
| Color | Silver |
| Connection | Point piece x Waltz |
| Dimension A | 32mm |
| Dimension B | 25mm |
| Dimension C | 12mm |
| Dimension D | 76,4mm |
| Dimension E | 93mm |
| Flange Diameter | 93mm |
| Material technical | Stainless steel 304 (1.4301) |
| Model | Point pieces |
| Roughness Material | <0.8 µm |
| Side A - Size | 3" DIN 11851 Point piece |
| Side B - Size | Waltz |
| Thread | 76,4mm |
| Type 2 | Roll point piece |
| Work pressure | 25 |
| Material | Stainless steel 304 |
| Also found under | |
| Milk Fittings DIN 11851 | |
