Sliding Bearing - Cylindrical Bushing - NOX-MET - Niro / PTFE - 120/125x70 mm

  • Item number: NXZ.12070
  • Brand: GLT
Delivery time unknown.
Choose inner diameter
3 mm
4 mm
5 mm
6 mm
7 mm
8 mm
9 mm
10 mm
11 mm
12 mm
13 mm
14 mm
15 mm
15.875 mm
16 mm
17 mm
18 mm
19 mm
20 mm
22 mm
24 mm
25 mm
26 mm
28 mm
30 mm
32 mm
34 mm
35 mm
36 mm
38 mm
40 mm
42 mm
44 mm
45 mm
48 mm
50 mm
52 mm
55 mm
60 mm
65 mm
70 mm
72 mm
75 mm
80 mm
85 mm
90 mm
95 mm
100 mm
105 mm
110 mm
115 mm
120 mm
125 mm
130 mm
135 mm
140 mm
145 mm
150 mm
155 mm
160 mm
165 mm
170 mm
175 mm
180 mm
185 mm
188 mm
190 mm
195 mm
200 mm
205 mm
210 mm
215 mm
218 mm
220 mm
225 mm
230 mm
235 mm
240 mm
245 mm
250 mm
255 mm
260 mm
265 mm
270 mm
275 mm
280 mm
285 mm
290 mm
295 mm
300 mm
340 mm
400 mm
Choose outer diameter
4.5 mm
5.5 mm
7 mm
8 mm
9 mm
10 mm
11 mm
12 mm
13 mm
14 mm
15 mm
16 mm
17 mm
18 mm
18.258 mm
19 mm
20 mm
21 mm
22 mm
23 mm
24 mm
25 mm
27 mm
28 mm
30 mm
32 mm
34 mm
36 mm
38 mm
39 mm
40 mm
42 mm
43 mm
44 mm
46 mm
48 mm
50 mm
52 mm
55 mm
57 mm
60 mm
65 mm
70 mm
75 mm
77 mm
80 mm
85 mm
90 mm
95 mm
100 mm
105 mm
110 mm
115 mm
120 mm
125 mm
130 mm
135 mm
140 mm
145 mm
150 mm
155 mm
160 mm
165 mm
170 mm
175 mm
180 mm
185 mm
190 mm
193 mm
195 mm
200 mm
205 mm
210 mm
215 mm
220 mm
223 mm
225 mm
230 mm
235 mm
240 mm
245 mm
250 mm
255 mm
260 mm
265 mm
270 mm
275 mm
280 mm
285 mm
290 mm
295 mm
300 mm
305 mm
335 mm
345 mm
405 mm
Choose length
3 mm
4 mm
5 mm
5.5 mm
6 mm
6.5 mm
7 mm
8 mm
9 mm
10 mm
10.5 mm
11.5 mm
12 mm
14 mm
15 mm
15.875 mm
16 mm
17 mm
17.5 mm
18 mm
20 mm
22 mm
22.5 mm
23.5 mm
25 mm
26 mm
28 mm
30 mm
32 mm
35 mm
37.5 mm
38 mm
40 mm
42.5 mm
45 mm
48 mm
49 mm
50 mm
55 mm
57 mm
60 mm
62.5 mm
65 mm
70 mm
75 mm
80 mm
85 mm
89 mm
90 mm
100 mm
110 mm
115 mm
120 mm
130 mm
140 mm
150 mm
160 mm
200 mm
250 mm
Choose inner diameter
3 mm
4 mm
5 mm
6 mm
7 mm
8 mm
9 mm
10 mm
11 mm
12 mm
13 mm
14 mm
15 mm
15.875 mm
16 mm
17 mm
18 mm
19 mm
20 mm
22 mm
24 mm
25 mm
26 mm
28 mm
30 mm
32 mm
34 mm
35 mm
36 mm
38 mm
40 mm
42 mm
44 mm
45 mm
48 mm
50 mm
52 mm
55 mm
60 mm
65 mm
70 mm
72 mm
75 mm
80 mm
85 mm
90 mm
95 mm
100 mm
105 mm
110 mm
115 mm
120 mm
125 mm
130 mm
135 mm
140 mm
145 mm
150 mm
155 mm
160 mm
165 mm
170 mm
175 mm
180 mm
185 mm
188 mm
190 mm
195 mm
200 mm
205 mm
210 mm
215 mm
218 mm
220 mm
225 mm
230 mm
235 mm
240 mm
245 mm
250 mm
255 mm
260 mm
265 mm
270 mm
275 mm
280 mm
285 mm
290 mm
295 mm
300 mm
340 mm
400 mm
Choose outer diameter
4.5 mm
5.5 mm
7 mm
8 mm
9 mm
10 mm
11 mm
12 mm
13 mm
14 mm
15 mm
16 mm
17 mm
18 mm
18.258 mm
19 mm
20 mm
21 mm
22 mm
23 mm
24 mm
25 mm
27 mm
28 mm
30 mm
32 mm
34 mm
36 mm
38 mm
39 mm
40 mm
42 mm
43 mm
44 mm
46 mm
48 mm
50 mm
52 mm
55 mm
57 mm
60 mm
65 mm
70 mm
75 mm
77 mm
80 mm
85 mm
90 mm
95 mm
100 mm
105 mm
110 mm
115 mm
120 mm
125 mm
130 mm
135 mm
140 mm
145 mm
150 mm
155 mm
160 mm
165 mm
170 mm
175 mm
180 mm
185 mm
190 mm
193 mm
195 mm
200 mm
205 mm
210 mm
215 mm
220 mm
223 mm
225 mm
230 mm
235 mm
240 mm
245 mm
250 mm
255 mm
260 mm
265 mm
270 mm
275 mm
280 mm
285 mm
290 mm
295 mm
300 mm
305 mm
335 mm
345 mm
405 mm
Choose length
3 mm
4 mm
5 mm
5.5 mm
6 mm
6.5 mm
7 mm
8 mm
9 mm
10 mm
10.5 mm
11.5 mm
12 mm
14 mm
15 mm
15.875 mm
16 mm
17 mm
17.5 mm
18 mm
20 mm
22 mm
22.5 mm
23.5 mm
25 mm
26 mm
28 mm
30 mm
32 mm
35 mm
37.5 mm
38 mm
40 mm
42.5 mm
45 mm
48 mm
49 mm
50 mm
55 mm
57 mm
60 mm
62.5 mm
65 mm
70 mm
75 mm
80 mm
85 mm
89 mm
90 mm
100 mm
110 mm
115 mm
120 mm
130 mm
140 mm
150 mm
160 mm
200 mm
250 mm
Delivery time or price unknown. Request a quote for price and delivery time.
Quick navigation:
Product description
Specifications
Pros and cons
  • Stainless steel
  • No maintenance
  • DIN 1494 / ISO 3547
  • Free of lead
Specifications
Article number NXZ.12070
EAN 04062011293426
applicable forExcellent sliding and wear behaviour, for all types of movement, high load capacity, good corrosion resistance.
As tollerantief7
Diameter HuisH7
Dimensions120/125x70 mm
Dynamic load≤ 140 N/mm² N/mm2
Friction value0,02 up to 0,18 µ
Inner diameter120 mm
Maintenance requiredmaintenance free
Materiaal Glij oppervlakPTFE
MaterialNiro / PTFE
Material technicalstainless steel (1.4301)
ModelCylinder liner
Model 2NOX-MET
Model DescriptionMaintenance-free sliding bearing
NormDIN 1494 / ISO 3547
Outer diameter125 mm
Rotation speed≤ 2,0 m/s
Static Load≤ 250 N/mm² N/mm2
Temperatur range–200 to +280°C
TypeZB
Length70 mm
Dimensions and weight
Length/depth7 cm
Width12,5 cm
Height12,5 cm
Dimension7 x 12,5 x 12,5 cm ( L x B x H)
Packaging dimensions
Length7 cm
Width12,5 cm
Height12,5 cm
Weight0 kg
download Download/print specifications PDF
Sliding Bearing - Cylindrical Bushing - NOX-MET - Niro / PTFE - 120/125x70 mm
Product description

Sliding Bearing - Cylindrical Bushing - NOX-MET - Niro / PTFE - 120/125x70 mm


NOX-MET is a versatile, corrosion-resistant dry sliding bearing with PTFE sliding layer. Therefore, no lubrication is necessary. However, additional lubrication is possible in principle!
Wrapped composite sliding bearing Stainless steel / PTFE coated | Maintenance-free dry sliding bearing | Corrosion resistance | DIN 1494 / ISO 4110
Delivery time or price unknown. Request a quote for price and delivery time.
