Sliding Bearing - Cylindrical Bushing - POM-MET - Steel / POM - 123/128x36 mm

  • Article number: 73309
  • Brand: GLT
Choose length
1
5
6
8
10
10.2
12
14
15
16
18
19
20
21.8
22
22.5
23
24
25
25.5
27.5
28
29
30
32
33
34
35
36
38
38.1
40
40.5
43
44
45
46
47
47.625
50
51.2
54
55
58
60
63
65
69
70
75
77
80
85
90
92
94.7
95
100
110
115
120
130
135
140
145
150
155
160
190
Choose inner diameter
5
6
7
8
10
12
13
14
15
16
17
18
20
22
24
25
26
27
28
30
32
34
35
36
37
38
40
43
44.45
45
47.625
50
55
60
63
65
70
75
80
85
90
95
100
105
110
115
120
123
125
130
135
140
145
150
155
160
165
170
175
180
190
195
200
205
210
220
225
229.8
230
239
240
250
260
280
295
300
318
320
355
360
405
430
510
Choose outer diameter
7
8
9
10
12
14
15
16
17
18
19
20
22
23
25
27
28
30
31
32
34
36
38
39
40
41
42
44
47
49.213
50
52.387
55
60
65
68
70
75
80
85
90
95
100
105
110
115
120
125
128
130
135
140
145
150
155
160
165
170
175
180
185
195
200
205
210
215
225
230
235
244
245
255
265
285
300
305
323
325
360
365
410
435
515
Choose length
1
5
6
8
10
10.2
12
14
15
16
18
19
20
21.8
22
22.5
23
24
25
25.5
27.5
28
29
30
32
33
34
35
36
38
38.1
40
40.5
43
44
45
46
47
47.625
50
51.2
54
55
58
60
63
65
69
70
75
77
80
85
90
92
94.7
95
100
110
115
120
130
135
140
145
150
155
160
190
Choose inner diameter
5
6
7
8
10
12
13
14
15
16
17
18
20
22
24
25
26
27
28
30
32
34
35
36
37
38
40
43
44.45
45
47.625
50
55
60
63
65
70
75
80
85
90
95
100
105
110
115
120
123
125
130
135
140
145
150
155
160
165
170
175
180
190
195
200
205
210
220
225
229.8
230
239
240
250
260
280
295
300
318
320
355
360
405
430
510
Choose outer diameter
7
8
9
10
12
14
15
16
17
18
19
20
22
23
25
27
28
30
31
32
34
36
38
39
40
41
42
44
47
49.213
50
52.387
55
60
65
68
70
75
80
85
90
95
100
105
110
115
120
125
128
130
135
140
145
150
155
160
165
170
175
180
185
195
200
205
210
215
225
230
235
244
245
255
265
285
300
305
323
325
360
365
410
435
515
Delivery time or price unknown. Request a quote for price and delivery time.
Quick navigation:
Product description
Specifications
Specifications
Article number 73309
EAN 04062011206143
Length36 mm
applicable forSuitable for grease or oil lubrication and all kinds of movement, good load capacity, robust and insensible to dirt.
Dimensions123/128x36 mm
Dynamic load≤ 140 N/mm² N/mm2
Friction value0,04 to 0,12 µ
Housing diameterH7
Inner diameter123 mm
Maintenance requiredlow maintenance
MaterialSteel / POM
Material technicalTin-plated steel (1.0330) + Acetal resin / POM
ModelCylinder liner
Model 2POM-MET
NormDIN 1494 / ISO 3547
Outer diameter128 mm
Rotation speed≤ 2,5 m/s
Shaft toleranceh8
Sliding surface materialAcetal resin / POM
Static Load≤ 250 N/mm² N/mm2
Temperatur range–40 to +130 °C
TypeZB
Sliding Bearing - Cylindrical Bushing - POM-MET - Steel / POM - 123/128x36 mm
Product description

Sliding Bearing - Cylindrical Bushing - POM-MET - Steel / POM - 123/128x36 mm


POM-MET is a low-maintenance composite sliding bearing with a POM coating. Initial lubrication is required. Both oil or grease lubrication are possible. Due to the lubricant pockets, relubrication intervals are significantly reduced! Suitable for all sliding movements, good load capacity, robust and resistant to dirt.
Wrapped composite sliding bearing steel / POM | low-maintenance | With lubrication pockets | DIN 1494 / ISO 3965
