Sliding bearing - Cylindrical Bearing - BRO-MET - Bronze - 12/14x15 mm

Sliding bearing - Cylindrical Bearing - BRO-MET - Bronze - 12/14x15 mm

  • Item number: BMZ.1215
  • Brand: GLT
local_shipping Before 13:00 ordered, shipped the same day
Choose inner diameter
5 mm
6 mm
8 mm
10 mm
12 mm
13 mm
14 mm
15 mm
16 mm
17 mm
18 mm
20 mm
22 mm
24 mm
25 mm
26 mm
27 mm
28 mm
30 mm
32 mm
34 mm
35 mm
36 mm
38 mm
40 mm
40.5 mm
42 mm
44 mm
44.45 mm
45 mm
47 mm
50 mm
50.5 mm
55 mm
60 mm
65 mm
70 mm
72 mm
75 mm
78 mm
80 mm
85 mm
90 mm
95 mm
100 mm
105 mm
110 mm
115 mm
120 mm
125 mm
130 mm
135 mm
140 mm
145 mm
150 mm
155 mm
160 mm
165 mm
170 mm
180 mm
190 mm
195 mm
200 mm
210 mm
215 mm
220 mm
225 mm
230 mm
235 mm
250 mm
260 mm
265 mm
270 mm
275 mm
280 mm
285 mm
289 mm
300 mm
515 mm
Choose outer diameter
7 mm
8 mm
10 mm
12 mm
14 mm
15 mm
16 mm
17 mm
18 mm
19 mm
20 mm
21 mm
22 mm
23 mm
24 mm
25 mm
27 mm
28 mm
29 mm
30 mm
31 mm
32 mm
34 mm
35 mm
36 mm
38 mm
39 mm
40 mm
42 mm
44 mm
45 mm
46 mm
48 mm
50 mm
50.8 mm
55 mm
56 mm
57 mm
60 mm
65 mm
70 mm
75 mm
77 mm
80 mm
83 mm
85 mm
90 mm
95 mm
100 mm
105 mm
110 mm
115 mm
120 mm
125 mm
130 mm
135 mm
140 mm
145 mm
150 mm
155 mm
160 mm
165 mm
170 mm
175 mm
185 mm
195 mm
200 mm
205 mm
215 mm
220 mm
225 mm
230 mm
235 mm
240 mm
255 mm
265 mm
270 mm
275 mm
280 mm
285 mm
290 mm
294 mm
305 mm
520 mm
Choose length
5 mm
6 mm
7 mm
8 mm
9 mm
10 mm
11.5 mm
11.8 mm
12 mm
14 mm
15 mm
16 mm
17 mm
18 mm
18.5 mm
19 mm
20 mm
22 mm
22.5 mm
23 mm
24 mm
25 mm
26 mm
28 mm
30 mm
31 mm
32 mm
34 mm
35 mm
37.5 mm
38 mm
40 mm
43 mm
45 mm
49 mm
50 mm
50.8 mm
53 mm
54 mm
55 mm
57 mm
58 mm
60 mm
63 mm
64 mm
65 mm
70 mm
75 mm
80 mm
90 mm
95 mm
100 mm
110 mm
115 mm
120 mm
125 mm
140 mm
150 mm
155 mm
160 mm
200 mm
250 mm
265 mm
€ 52,50 per 35 piece(s) incl. VAT
€ 52,50 excl. VAT
€ 1,50 per 1 piece(s)
piece(s)
Choose inner diameter
5 mm
6 mm
8 mm
10 mm
12 mm
13 mm
14 mm
15 mm
16 mm
17 mm
18 mm
20 mm
22 mm
24 mm
25 mm
26 mm
27 mm
28 mm
30 mm
32 mm
34 mm
35 mm
36 mm
38 mm
40 mm
40.5 mm
42 mm
44 mm
44.45 mm
45 mm
47 mm
50 mm
50.5 mm
55 mm
60 mm
65 mm
70 mm
72 mm
75 mm
78 mm
80 mm
85 mm
90 mm
95 mm
100 mm
105 mm
110 mm
115 mm
120 mm
125 mm
130 mm
135 mm
140 mm
145 mm
150 mm
155 mm
160 mm
165 mm
170 mm
180 mm
190 mm
195 mm
200 mm
210 mm
215 mm
220 mm
225 mm
230 mm
235 mm
250 mm
260 mm
265 mm
270 mm
275 mm
280 mm
285 mm
289 mm
300 mm
515 mm
Choose outer diameter
7 mm
8 mm
10 mm
12 mm
14 mm
15 mm
16 mm
17 mm
18 mm
19 mm
20 mm
21 mm
22 mm
23 mm
24 mm
25 mm
27 mm
28 mm
29 mm
30 mm
31 mm
32 mm
34 mm
35 mm
36 mm
38 mm
39 mm
40 mm
42 mm
44 mm
45 mm
46 mm
48 mm
50 mm
50.8 mm
55 mm
56 mm
57 mm
60 mm
65 mm
70 mm
75 mm
77 mm
80 mm
83 mm
85 mm
90 mm
95 mm
100 mm
105 mm
110 mm
115 mm
120 mm
125 mm
130 mm
135 mm
140 mm
145 mm
150 mm
155 mm
160 mm
165 mm
170 mm
175 mm
185 mm
195 mm
200 mm
205 mm
215 mm
220 mm
225 mm
230 mm
235 mm
240 mm
255 mm
265 mm
270 mm
275 mm
280 mm
285 mm
290 mm
294 mm
305 mm
520 mm
Choose length
5 mm
6 mm
7 mm
8 mm
9 mm
10 mm
11.5 mm
11.8 mm
12 mm
14 mm
15 mm
16 mm
17 mm
18 mm
18.5 mm
19 mm
20 mm
22 mm
22.5 mm
23 mm
24 mm
25 mm
26 mm
28 mm
30 mm
31 mm
32 mm
34 mm
35 mm
37.5 mm
38 mm
40 mm
43 mm
45 mm
49 mm
50 mm
50.8 mm
53 mm
54 mm
55 mm
57 mm
58 mm
60 mm
63 mm
64 mm
65 mm
70 mm
75 mm
80 mm
90 mm
95 mm
100 mm
110 mm
115 mm
120 mm
125 mm
140 mm
150 mm
155 mm
160 mm
200 mm
250 mm
265 mm
€ 52,50 per 35 piece(s) incl. VAT
€ 52,50 excl. VAT
€ 1,50 per 1 piece(s)
piece(s)
check25 years of experience
check Customer review 9,2/10
More than 5 pieces? Click here for quote
paypal
creditCard
Google Pay
Apple Pay
Quick navigation:
Product description
Specifications
Pros and cons
  • Bronze with lubricant depots
  • Low maintenance
  • Resistant to corrosion
  • For heavy Loads
Specifications
In stock Yes, 770 pcs
Article number BMZ.1215
EAN 04062011011938
Minimum sold per 5
applicable forHigh load capacity and stability at low abrasion, suited for rough operation, corrosion resistant.
As tollerantief7
Diameter HuisH7
Dimensions12/14x15 mm
Dynamic load≤ 40 N/mm² N/mm2
Friction value0,05 up to 0,12 µ
In stock link2025-12-15
Inner diameter12 mm
Maintenance requiredlow maintenance
MaterialBronze
Material technicalBronze (CuSn8P)
ModelCylinder liner
Model 2BRO-MET
Model DescriptionPlain bearing with grease pockets
NormDIN 1494 / ISO 3547
Outer diameter14 mm
Rotation speed≤ 2,5 m/s
Static Load≤ 120 N/mm² N/mm2
Temperatur range-40 up to +250 °C
TypeZB
Length15 mm
Dimensions and weight
Length/depth1,5 cm
Width1,4 cm
Height1,4 cm
Dimension1,5 x 1,4 x 1,4 cm ( L x B x H)
Packaging dimensions
Length1,5 cm
Width1,4 cm
Height1,4 cm
Weight0 kg
Also found under
Sliding Bearings
download Download/print specifications PDF
Sliding bearing - Cylindrical Bearing - BRO-MET - Bronze - 12/14x15 mm
Product description

Sliding bearing - Cylindrical Bearing - BRO-MET - Bronze - 12/14x15 mm


BRO-MET is a low-maintenance bronze plain bearing. However, initial lubrication is required—both oil and grease lubrication are possible. Due to the lubricant depots, relubrication intervals are significantly reduced! High load capacity and strength with low wear, suitable for rough operation, corrosion resistant.
Wrapped bronze sliding bearing with lubrication pockets/ CuSn8P (DIN 17662) | Low-maintenance | DIN 1494 / ISO 4075
